S6 Close Type Hydraulic Quick Coupling

S6 Close Type Hydraulic Quick Coupling

by Valvenok
Save 30% Save 30%
£8.54
£3.66 - £40.70
£8.54
£5.98
£2.56 - £28.49
£5.98

S6 open and close hydraulic quick coupling product parameters:
Product model: S6
Product material: carbon steel, stainless steel, brass
Temperature range: -25°C to +120°C
Rated pressure: 15-50Mpa
Ideal for: construction equipment, forestry equipment, agricultural machinery, petroleum equipment, steel equipment, chemicals and other required hydraulic applications
Specifications and models: 1/4, 3/8, 1/2, 3/4, 1, etc.

S6 open and close hydraulic quick coupling product features:
1. The product is produced according to the ISO7241-A international standard
2. Needle valve design can increase the flow of fluid
3. Locking ball system for quick connection and disconnection of the ball head
4. The key parts are induction hardened, with good durability
Body Size(in) 1/4 3/8 1/2 3/4 1
Rated Pressure(PSI) 5000 4000 4000 3000 3000
Rated Flow(GPM) 3 6 12 28 50
Temperature Range                       -20℃ to +120℃
Standard seal material  NBR





    Part No.: S6-02SF
