KZE Close Type Hydraulic Quick Coupling
KZE Close Type Hydraulic Quick Coupling product parameters:
Product model: KZE
Product material: carbon steel, stainless steel, brass
Temperature range: -20°C to +120°C
Rated pressure: 31.5Mpa
Interchangeability: Parker 6600 series, Express ANV series, Eric 5600 series, Hansen HA15000 series
Ideal for: construction equipment, forestry equipment, agricultural equipment, hydraulic implements, steel equipment and other required hydraulic applications
Specifications and models: 1/4, 3/8, 1/2, 3/4, 1, etc.
KZE Close Type Hydraulic Quick Coupling product features:
1. The product is produced according to the ISO7241-A international standard
2. Locking ball system for quick connection and disconnection of the ball head
3. The key parts are induction hardened, with good durability
4. The female socket and male plug are precision-made by solid bar
| Body Size(in) | 1/8 | 1/4 | 3/8 | 1/2 | 3/4 | 1″ | 1-1/4 | 1-1/2 | 2″ |
| Body Size(metric) | M14 | M16/M18 | M20/M22 | M27 | |||||
| Rated Pressure(PSI) | 5000 | 3000 | 3000 | 3000 | 3000 | 3000 | 2000 | 2000 | 1500 |
| Temperature Range | -20℃ to +120℃ | ||||||||
| Standard seal material | NBR | ||||||||
