KZE-BA Thread Locked Type Hydraulic Quick Coupling

Save 30% Save 30%
Original price £9.81
Original price £4.21 - Original price £36.73
Original price £9.81
Current price £6.87
£2.95 - £25.71
Current price £6.87

// Applications
Mobile equipment, agricultural machines and universal industrial equipment.
 // Features
·New valve design, which can resist damage from high flow and the pressure of impulse, that provides advanced performance
 ·Machined from solid steel barstock for durability
 ·The KZE-BA series employs a threaded sleeve locking mechanism that mates with
    matching male threads on the nipple. The two halves must be manually threaded together at the connection.
 ·New chrome plating treatment provides advanced anti-rust performance.
 ·Compatible with GROMELLE 6000 Series and HOLMBURY TGW series.

Body Size(in) 1/4 3/8 1/2 3/4 1
Rated Pressure(PSI) 10000 10000 10000 8500 6000
Rated Flow(GPM) 3 6 12 28 50
Temperature Range -20℃ to +120℃
Standard seal material  NBR


Part No.: KZE-BA-02SF
