KZD Pneumatic And Hydraulic Quick Coupling

KZD medium pressure high performance gas-liquid quick coupling product parameters:
Product model: KZD
Product material: brass
Temperature range: -20°C to +120°C
Rated pressure: 6.9Mpa
Ideal for: construction equipment, forestry equipment, agricultural machinery, petroleum equipment, steel equipment, chemicals and other required hydraulic applications
Specifications and models: 1/4, 3/8, 1/2, 3/4, 1, etc.
KZD medium pressure high performance gas-liquid quick oupling product features:
1. The product is produced according to the ISO7241-B international standard
2. Needle valve design can increase the flow of fluid
3. Locking ball system for quick connection and disconnection of the ball head
4. The key parts are induction hardened, with good durability
