FF Flat Face Type Hydraulic Quick Coupling

FF Flat Face Type Hydraulic Quick Coupling

by Valvenok
Save 30% Save 30%
£24.31
£10.43 - £523.54
£24.31
£17.02
£7.30 - £366.48
£17.02

FF Flat Face Type Hydraulic Quick Coupling product parameters:
Product model: ISO16028
Product material: carbon steel, stainless steel, brass
Temperature range: -25°C to +125°C
Rated pressure: 35Mpa
Ideal for: construction, railroad maintenance, hydraulic tools in mining, special environments where easy to clean up
Specifications and models: 1/4, 3/8, 1/2, 3/4, 1, etc.

FF Flat Face Type Hydraulic Quick Coupling product features:
1. The product is produced according to the ISO16028 international standard
2. Locking ball system for quick connection and disconnection of the ball head
3. The key parts are induction hardened, with good durability

Body Size(in) 1/4(02) 3/8(03) 1/2(04) 5/8(06) 3/4(08) 1(10) 1-1/2(12) 2(16)
Rated Pressure(PSI)  5000 4350 4350 3625 3625 3000 3000 3000
Rated Flow(GPM)  3 6 12 20 28 50 80 100
  Spillage(ML) 0.006 0.012 0.02 0.026 0.032 0.035 0.05 0.1
Temperature Range -20℃ to +120℃
Standard seal material NBR



Part No.: FF-02SF
