Pressure Reducing Sandwich Valve - PARKER
Parker pilot operated pressure reducing valves series PRM in size NG06 / CETOP 03 ensure a long service life due to valve bodies manufactured from steel. The sandwich design enables an easy configuration of stack systems. The piloting results in a flat p/Q performance curve.
The reducing function is located in port P. The pressure reduction for the desired connecting port is achieved by internal connections of the pilot and drain lines with the corresponding channels.
Markets:
• Industrial
Features/Benefits:
• Valve bodies are made of steel - extra strength and durability
• Internal hardened steel components - provide longer service life
• Wide pressure range - makes selection easy
• Short delivery time for most versions - no warehousing necessary
• Piloting results in a flat p/Q performance curve
• The control pressure range can be set by hexagon socket screw
• Pressure gauge/measuring connections are available in the valve body(only available in PP function)
Applications:
• Suitable for general hydraulic applications.
| Pressure Range (bar): | 27 - 140 |
| Function: | PP - Reduction in port P |
| Body Material: | Steel |
| Maximum Operating Temperature: | 60 °C |
| Minimum Operating Temperature: | -20 °C |
| Mounting Type: | Sandwich plate |
| Operation Type: | Pilot |
| Actuation Type: | Manually |
| Product Series: | Pressure reducing |
| Size: | NG06 nom |
| Adjustment Mechanism: | Hexagon socket |
| Seal Material: | V - FPM |
| Maximum Operating Pressure: | 350 bar |
| Weight: | 1.95 kg |
| Maximum Flow Rate: | 40 L/min |
| Minimum Fluid Temperature: | -20 °C |
| Maximum Fluid Temperature: | 80 °C |
